Industrial Condenser Units - GYBOX
Coils
Manufactured in pipe diameter of 3/8" with wall thickness of 0.35 mm, in a staggered arrangement and with Copper Collector
Aluminum fin with special high efficiency blasted surface is used. Fin spacing is 2.1 mm and mold geometry is designed as 25x22 mm.
Cabinet
Industrial Type GYBOX Cabinet Condenser cabinets are resistant to different weather conditions and are produced from galvanized steel, painted with RAL 9016 electrostatic powder paint.
Fan
Industrial Type GYBOX Cabinet Condensers use Ø350, Ø400, Ø450, Ø500, Ø630, Ø800 mm fans operating at 1400 rpm or 900 rpm.
Optional fan model changes can be applied.
The operating temperature range is -40/+50 °C.
Capacity
Capacities are calculated according to EN 328 Standards for R404A refrigerant at dT=15K compared to European fans.
Test
Industrial Type GYBOX Cabinet Condensers are tested at 40 bar and shipped at 6 bar with nitrogen.
